RYT-250F

Hi, how can I help you?Chat Now!

  • Model Number：   RYT-250F
  • Rated Power：   200W
  • Application：  The industrial computer, check machine, machine
  • Fan Type：  4cm
  • Power Type：  Desktop / industrial computer
  • Input Voltage：  115/230Vac
  • High efficiency：  85%
  • Dimention：  150x81.5x43mm
  • Packaging Details：  12pcs/ctn
  • Carton Dimention：  500x350x110mm

10 Other Products in the same category

Product Features

• In accordance with Flex12V version 2.0
• High efficiency
• Low output ripple noise
• Each output with over voltage protection
• Each output voltage with short-circuit protection
• 4CM fan
• 100% high temperature aging test (50℃)
• Life cycle: more than 80KH hours

Product Details

Connector
    • Motherboard cable (20+4-Pin) x 1
    • CPU power Cable (works as either 4 or 8-Pin) x 1
    • 4-Pin peripheral cable x 2
    • SATA cable x 2
    • Floppy power adapter cable x 1

    • Motherboard Cable

      20+4-Pin*1

    • CPU power Cable

      4-Pin*1

    • HDD power Cable

      SATA*2

    • HDD power Cable

      4-Pin*2\4-Pin*1

Parameters
  • AC Input: 115/220V，5A/3A，47-63Hz
    DC Output:
    • +3.3V(Orange):
    • 12A
    • +5V(Red):
    • 16A
    • +12V1(Yellow):
    • 8A
    • -12V(Blue):
    • 0.5A
    • +5VSB(Purple):
    • 1.5A
    • -5V(White):
    • -A
    Output power: Max Power：250W，Rated Power：200W
Parameters
    • PFC type：No
    • Protection function： OVP， OPP， SCP
    • Cooling system: SPEED: 6000RMP(+/-10%)
      TEMP.AUTO ONTROL: 2500rpm at 41.7℃~5000rpm at 60.5℃
      4CM Fan
      Noise: 18dB at 5000rpm
    • P.G signal: 100-500ms
    • Keep time: 17ms(min)
    • Conversion efficiency：75%
    • MTBF：100000 hours
    • Working temperature：0-50℃
Accessories
    • Packing list：
      Power Supply x1
