SD-200D

Hi, how can I help you?Chat Now!

  • Model Number：   SD-200D
  • Rated Power：   200W
  • Application：  Fiscal machine, Industrial PC, All-in one machine ,etc.
  • Fan Type：  Natural cooling
  • Power Type：  Desktop / industrial computer// the on-board computer
  • Input Voltage：  12VDC
  • High efficiency：  94%
  • Dimention：  61x57x11mm
  • Packaging Details：  50pcs/ctn
  • Carton Dimention：  -

10 Other Products in the same category

Product Features

* Rated output power:200W (200W Max)
* High efficiency & thin Size
*100% burin-in test & hi-pot test
*Efficiency: 94% (min) at full load
*Over-voltage, over-current and over-power protection
*Output voltage with short circuit current protection
*Application for 1U size
*Open frame design
*Life Cycle:≥80K hours
*Support remote control function and sleep mode
*Connectors: 20Pin for M/B,4pin for 12VCPU,SATA*1,4Pin for HDD*1，FDD*1

Product Details

Connector
    • Motherboard cable (20-Pin) x 1
    • CPU power Cable (works as either 4 or 8-Pin) x 1
    • 4-Pin peripheral cable x 1
    • SATA cable x 1
    • Floppy power adapter cable x 1

    • Motherboard Cable

      20-Pin*1

    • CPU power Cable

      4-Pin*1

    • HDD power Cable

      4-Pin*1\SATA*1\4-Pin*1

Parameters
  • AC Input: 12VDC，15A/12VDC
    DC Output:
    • +3.3V(Orange):
    • 6A
    • +5V(Red):
    • 6A
    • +12V1(Yellow):
    • 12A
    • -12V(Blue):
    • 0.1A
    • +5VSB(Purple):
    • 2A
    • -5V(White):
    • -A
    Output power: Max Power：200W，Rated Power：200W
Parameters
    • PFC type：No
    • Protection function： OVP， OPP， SCP
    • Cooling system:Natural cooling
    • P.G signal: 100-500ms
    • Keep time: 2ms(min)
    • Conversion efficiency：94%
    • MTBF：100000 hours
    • Working temperature：-10℃ to +50℃
    • Storage temperature：-40℃ to +85℃
    • Relative humidity：5% to 95% RH
    • Vibration standard：5-500 Hz,2.4G rms
Accessories
    • Packing list：
      Power Supply x1
